Separate control box that can be used in combination with a 500, 600 or 750 Watt mini motor. By choosing the correct mini motor for your sewing machine application a wide variety of sewing machine models can be equipped with this control unit (including direct drive). Operating panel C300 (i70) is optional.
Available functions (depending on the control box model):
trimmer, wiper, tension release, presser foot lift, reverse, HP function, second stitch length, puller, material guide, photocell input, flip flop function and IOT-system.
i60 and i70 models use a separate speed control unit that can be installed in a random position under the table, therefore very convenient for long arm machines.
Available i70 models: Dürkopp Adler (i70L) , Global, Brother, Mitsubishi, Pegasus (i70M), Juki.
Mini motors for i60, i70 series:
i60 and i70 series work in combination with a separate mini motor. With the 500, 600 and 750 Watt models a wide
range of sewing applications is covered. The mini motors for under the table are supplied including mounting
bracket, V-belt cover and motor pulley.
Also a variety of direct drive models are available.
Full function control unit and speed control unit. Mini motor is not included.
i70M-4-11-220 – Mitsubishi model
i70M-4-7W-220 – Juki model
i70M-4-BR-220 – Brother model
i70L-4-ED-220 – for various Global & DA postbed models
Minimotors for i70 series:
MT0150 – Mini motor 500 Watt for under table mounting
MT0160 – Mini motor 600 Watt for under table mounting
MT0175 – Mini motor 750 Watt for under table mounting
MT0250 – Mini motor 500 Watt for direct drive machines (this motor is without bracket and has a built in synchronizer)
MT0260 – Mini motor 600 Watt for direct drive machines (this motor is without bracket and has a built in synchronizer)
MT0275 – Mini motor 750 Watt for direct drive machines (this motor is without bracket and has a built-in synchroniser)
MT0350 – Mini motor 500 Watt for Chain stitch machines (motor pulley 85) for under table mounting
Standard mini motor pulley size 75 mm
