BT 600 X 400 N

BT 600 X 400 N

For downloads see our downloads page for the BT Series.



The product specifications for the BT 600x400N are:

  • Complete table, stand and motor
  • Machine speed: Max. 2000 SPM
  • Feeding system: by pulse motor (X-Y)
  • Hook type: large capacity hook
  • Stitch length: max 10 mm
  • Presser foot lift: max 16 mm
  • Clamp lift: up to 22 mm (pneumatic)
  • Needle type: DPx17
  • Sewing range: 600 x 400 mm
  • Power source: 240 V,  1 phase, 50 – 60 Hz, direct drive AC servomotor

Description

BT 600×400 N
This programmable pattern sewing machine is suitable to sew medium / heavy materials with a sewing area of 600 x 400 mm. The height of presser foot lifter can be adjusted by a stepping motor.
Patterns are programmable on the userfriendly touch panel. The left and right clamp can be programmed to move down independently. The machine is delivered complete with table top, stand and a direct drive mini servo motor. Maximum machine speed 2000 spm. The machine is equipped with bar code reader, quick release, thread breaking sensors and needle cooling (with arm presser).



Dahao Technologies allows you to design and modify patterns both on the easy to use touch panel and by software and can be directly downloaded by USB. Machine can read : .DXF .NSP .DST .SEW .EMB files

Additional information

Product

BT 100×100, BT 300×200
